Description
GB140, the AIS-140 certified vehicle tracking device based on advanced GSM and GNSS technology which can be used in tracking, I/O applications, serial data and real-time tracking with various Reports. Designed specifically for the Indian industry, it can be used in various industries such as logistics and transportation, taxi and cab aggregators, mining, school and employee transportation etc.
Features
Real-time tracking with GPS/Glonass- Multiple Input /output ports
- 2 Way Communication
- Emergency Button as per AIS 140
- Internal + external (optional) GNSS + GPS+GSM antenna
- Device Tampering Alert
- IP67 dustproof and waterproof
- Large battery backup
- Embedded Sim ( Dual sim support)
- ICAT, ARAI Certified and AIS 140 Approved Anti-Theft Device
- Emergency Response
- Driver Behaviour Monitoring
- Bluetooth OBD
Specification
| S. No. | PARAMETER | DESCRIPTION |
|---|---|---|
| 1. | Input Voltage | 8-42 VDC with surge protection |
| 2. | GPS RECEIVER | Support AGPS , SBAS ranging (WAAS, EGNOS,GAGAN, MSAS) 66 acquisition-channe Maximum Update Rate: 10Hz |
| 3. | GPS TRACKING SENSITIVITY | Tracking: -165 dBm Reacquisition: -160 dBm Cold starts: -147 dBm |
| 4. | GPS ACCURACY | 2.5 Meter-5 Meter |
| 5. | Bluetooth | Bluetooth: compliant with 3.0+EDR |
| 6. | GPRS DATA | GPRS class 12: max. 85.6 kbps (downlink/uplink)PBCCH support |
| 7. | GPRS DATA | GPRS class 12: max. 85.6 kbps (downlink/uplink) PBCCH support |
| 8. | PROTOCOL | Embedded TCP/HTTP protocol |
| 9. | JAMMING DETECTION | YES |
| 10. | Antenna (Internal + External) | GPS & GSM high gain Antenna |
| 11. | LED STATUS | Three LEDs for MCU, GPS and GSM status indication |
| 12. | Battery | 350mah (expandable upto 1050 mah) |
| 13. | Device Working Mode | Continuous Tracking Interval Tracking Sleep Mode and Deep Sleep Modes |
| 14. | Input / output | 4 digital outputs (2 AIS+2) 3 analog input 6 digital input 2 RS232 ( Serial Communication) 2 (1 wire protocol) 1 SOS |
| 15. | Memory | 32 Mb Non Volatile Memory , Stores upto 50000 strings data |
| 16. | Housing | IP 65 |
| 17. | Accelerometer | 6 Axis |
| 18. | Tamper Switch | Yes |
| 19. | Output Supply | 3.3 V,4.6 V |
| 20. | Accessories | GB 140 , 20 pin Wire, 16 pin wire,UserManual |
| 21. | Measurement (L*B*H mm)/ Weight (gm) | 100*100*36/100 |
